Cntl Knob

DESCRIPTION

The EHX Cntl Knob is an affordable, compact, easy-to-use pedal that delivers static remote control for devices with expression control jacks. It lets you set two preset values that represent two positions of a traditional expression pedal and toggle between them with its footswitch.

The pedal’s EXP 1 Knob selects the first expression setting and the EXP 2 Knob the second. On both, fully CCW corresponds to the heel position while fully CW to the toe position. LEDs indicate which knob is active and can be powered by your pedalboard’s power supply.

To maximize the Cntl Knob’s compatibility with other products it’s equipped with a TRS+/- Button that lets you match its expression polarity with the device being controlled. For extra convenience it comes equipped with a 6 foot TRS (Tip-Ring-Sleeve) cable.

  • Delivers static remote control for EHX pedals and those of other makers that are equipped with expression control jacks
  • Compact, affordable, easy-to-use
  • Toggle instantly between two preset expression pedal values
  • TRS+/- Button for maximum compatibility with devices by all makers
  • Equipped with a 6-foot TRS cable

SPECIFICATIONS

Circuit
Analog
Audio
Mono
Dimensions (in)
3.63 x 1.75 x 1.50
Current Draw
5mA
Year Released
2020
UPC
683274012292
Owner's Manual
EXP 1 KNOB
The position of this knob determines the first expression setting.
EXP 2 KNOB
The position of this knob determines the second expression setting.
TRS +/- BUTTON
When this button is in the inward position, the polarity of the EXP OUT jack is Ring-to-Wiper. When this button is in the outward position, the polarity of EXP OUT is Tip-to-Wiper.
FOOTSWITCH AND LEDs
A press on the footswitch toggles the active expression setting on EXP OUT between EXP 1 and EXP 2. If power is applied, the LEDs below each knob light to indicate the currently active knob.
EXP OUT JACK
This jack outputs the expression value set by the currently active knob. A TRS (tip-ring-sleeve) cable is required for this jack.

“If your pedalboard is a little cramped and you don’t require the ‘sweep’ of a traditional expression pedal, this handy little unit might be just what you need.”

–Gear News
